Steel Grit
Steel grit is fabricated by crushing, screening the resulting abrasive media and tempering it to the desired hardness. These abrasive Steel Grits are specially used in every type of wheel machine and also for blast room where nozzles are employed in air blasting. Their sharp edges help in cleaning, etching and smoothening of the blasting surface easily.
Steel Grit is made by crushing toughened shot after examination of abrasive media and tempering to achieve the desired hardness. It is utilized in rust elimination where the speed of cleaning is high and rough finish is suitable. Steel grit is a crushed steel shot. They are used for different applications (shot blasting, shipbuilding, pipe building, steel construction, granite cutting, tank manufacturing, etc.).
These products adopt the raw materials which are carefully selected, and are added with the alloys with the appropriate proportion, and are transformed into steel grains or steel grits after the electric furnace smelting process. After this high-temperature process, these steel grains break into steel grit which is further classified into various categories of grit by automatic screen classification.
Steel grit’s superior hardness and confined microstructure provides maximum durability or life and impact energy transfer. It provides a very fast stripping action for many types of surface cleaning from steels and other foundry metals. Softer than aluminum oxide, but still angular in shape, steel grit will not fracture as easily making it perfect for creating an etched surface on metal. Quickly strips contaminants from steel and foundry metals. Used in wheel blast and pressure blasting systems. Steel Grit effectively produces an etching on hard metal surfaces for better adhesion of coatings including paints, enamel and rubber.
We are the leading manufacturer of steel grit abrasives. This grit is good for serving to get rid of the contaminants from the surface of assorted product and it additionally creates a final profile for brand new coating to stick to the foremost common uses for steel grit area unit removing of mill scale, removing totally different degrees of coatings from the surface of product and a typical grit sizes that area unit most ordinarily used vary between G25 – G80. The larger the grits, the smaller are going to be the dimensions of the particular particle of blast media.
Our steel grit abrasives price is best with high quality. These smaller particles then produce a smaller blast profile on to the merchandise on the opposite hand the larger particles (the ones that have smaller G numbers) can produce a deeper blast profile. In associate addition to the depth of the blast profiles the larger particles can show a effectiveness within the removal of significant amounts of paint whereas the smaller lot of particles are going to be best suited to removing contaminants on lighter surfaces.
An additional profit connected to the steel grit is that it's the potential to be used multiple times before the necessity of replacement the grit arises. One will use mechanical blast media recovery instrumentality if you would like to recover and use the media once more. this permits the media to be used or so a hundred and fifty to two hundred times before it must get replaced with a recent blast media.
Name: |
GP steel grit |
GL steel grit |
GH steel grit |
?C? |
0.85-1.20 % |
||
?Mn? |
0.60-1.20 % |
||
?Si? |
0.50-1.20 % |
||
?S? |
≤0.05 % |
||
?P? |
≤0.05 % |
||
Hardness |
42-50HRC |
56-60HRC |
60-66HRC |
External firm |
Spheroid, semi-spheroid and flat granules <10% |
||
Microstructure |
Homogeneous tempered martensite and baintite |
||
Density |
7.4g/CC |
G10 |
2.00mm |
G12 |
1.70mm |
G14 |
1.40mm |
G16 |
1.18mm |
G18 |
1.00mm |
G20 |
0.850mm |
G25 |
0.710mm |
G30 |
0.600mm |
G40 |
0.425mm |
G50 |
0.300mm |
G70 |
0.180mm |
G80 |
0.120mm |
GP steel grit is an external form is rounded or cylindrical and shaped with steel water, owns a fine elasticity, and the strength of a fatigue resistance as a result of a fine heat treatment, applied in all aspects, special hardness steel has shot applied in strengthening a treatment.
GL steel grit is although stronger than GP steel grit, GL also loses its form are edges during a shot blasting and is particularly suited to descaling and surface preparation applications.
GH steel grit is having maximum hardness, GH always remains angular in its operating mix. These abrasives are particularly effective in a surface treatment processes, and produce a uniform, an etched finish, GH angular grit should only be used in wheel machines where working requirements take precedence over cost price considerations. For a use mainly with compressed an air a blasting equipment.
Application of using steel grit:
We are the largest Steel Grit Supplier in India, The smaller particles with larger variety like G80 grit can leave a one to two Mil profile and bigger particles sort of a G25 can leave deeper profiles that vary between four to six mils (this finding stands true once, all the opposite blast instrumentality settings stay the same). We also manufacture, supply and export shot blasting machine, sand blasting hopper, steel shots, abrasive garnet, metalizing wire, zinc wire, arc spray gun, flame spray gun, sand blasting machine, etc at a low price for sale.
